FlexxiFloat™ 100 Crop Lifter
Features
Specifications
Videos & Guides

The FlexxiFloat 100 crop lifter combines the flexibility of the FlexxiFloat™ series with the gentle lift of a nylon finger. The spring pivot attached to the rail allows the lifter to flex in varying ground conditions, while the nylon finger provides a gentle lift to the crop. The lifter and finger can be paired with the optional 20250 shoe to add increased wear on the tip of the nylon finger in particularly uneven or rocky soil conditions.

Benefits

Adjustable

The Flexxifinger® FlexxiFloat™ 100 has dual-adjustability. It is possible to change the angle of the nylon finger while the spring tensioned pivot mechanism permits the lifters to flex upwards in varying ground conditions. The adjustment screw can be used to limit the downward travel of the tip of the lifter.

Universal fit

The FlexxiFloat™ 100 Crop Lifter is compatible with virtually every guard system on the market.

Gentle on the Combine

The hybrid design of the FlexxiFloat™ 100 incorporates a replaceable nylon finger that is designed to act as the weakest point of the attachment. This minimizes the probability of steel components entering the combine if it breaks. When hitting an obstacle, the free-float fit on the knife guard allows the lifter to deflect and return to center.  This action greatly reduces the chance of damage to the lifter.

Easy to Maintain

A bent or broken nylon finger can be replaced in less than a minute, significantly reducing downtime in the field.

QD™ Compatible

Flexxifinger® uses the same patented QD™ technology on all its lifters, which makes it possible to quickly interchange different lifters on the same header without the need for removing the guard bolt each time.

Usage

Crop type: pulses, cereals, rice, oilseed, forage and other specialty crops

General recommendation is one lifter per foot across the header for solid-seeded crops. For maximum efficiency, lifters spacing may be customized to fit various row crop configurations.  Lifter spacing depends on row spacing, and whether entering the field with the rows, or on an angle.

The FlexxiFloat™ 100 Crop Lifter uses the 33060P nylon finger.  Please refer to specifications tab for additional product information.

** Some or all of these components are made of steel, therefore care must be exercised by the combine operator to minimize possible damage to the header/ combine.**

Optional Accessories

33080 Bean Lifting Pan
This pan attaches to the rail of the Flexxfinger’s® line of crop lifters and helps to:

  • Pull edible bean pods above the knife
  • Reduce shatter loss in dry field conditions by catching shelled seed that would otherwise be lost

32310 Carriage Bolt
This custom carriage bolt is for select headers that have a poly skid plate held on by a 7/16” (11mm) carriage step bolt from under the header. Our 32310 carriage bolt is 7/16" with the extra step and tapers to 10mm to fit the QD™ nut.

32312 Carriage Bolt
This custom carriage bolt is for a header that uses a 7/16” (11mm) carriage bolt from under the header. Our 32312 carriage bolt is 7/16" and tapers to 10mm to fit the QD™ nut.

32314 Carriage Bolt
This Carriage bolt is used on a header that has a 10mm guard bolt from under the header and fits the QD™ nut.

40090 Off-set Bracket
On headers that have 4”(100mm) spacing between the guards, there will be instances where the guard bolts do not line up with the guard point, making the installation of a lifter at specific intervals impossible. Flexxifinger® has engineered a patented bracket, to position a lifter on a guard tip that does not align with a bolt. This allows users to place Flexxifinger® lifters at intervals other than once every 12” (304mm).
